Silos Fundo Plano

Fabricados em aço galvanizado de alta resistência (ZAR345), os silos armazenadores possuem respiros em seu telhado, o que elimina a condensação de ar e garante alta luminosidade interna. Variando sua altura de 04 a 22 anéis, com diâmetro de 4,64 a 32,49 - sua capacidade de armazenagem vai de 900 à 245 mil sacas,cada saca equivalendo à 60kg.

Todos os equipamentos são adequados conforme as normativas vigentes. Mais informações sob consulta.

Confira abaixo o modelos disponíveis:

MODELO	DIÂMETRO Ø(m)	ALTURA CILINDRO (m)	ALTURA TOTAL (m)	VOLUME (m³)	CAPACIDADE - 750kg/m³ SCS.	CAPACIDADE - 750kg/m³ TON.
SAT 0404	4,64	3,62	5,76	67,90	900	54,00
SAT 0405	4,64	4,51	6,65	83,00	1.099	66,00
SAT 0406	4,64	5,40	7,54	98,00	1.299	77,90
SAT 0407	4,64	6,29	8,43	113,10	1.498	89,90
SAT 0408	4,64	7,18	9,32	128,10	1.697	101,80
SAT 0409	4,64	8,07	10,21	143,20	1.897	113,80
SAT 0504	5,57	3,62	6,03	99,80	1.322	79,30
SAT 0505	5,57	4,51	6,92	121,50	1.609	96,60
SAT 0506	5,57	5,40	7,81	143,20	1.897	113,80
SAT 0507	5,57	6,92	8,70	164,80	2.184	131,10
SAT 0508	5,57	7,18	9,59	186,50	2.472	148,30
SAT 0509	5,57	8,07	10,48	208,20	2.759	165,50
SAT 0704	7,43	3,62	6,57	184,40	2.443	146,60
SAT 0705	7,43	4,51	7,46	223,00	2.955	177,30
SAT 0706	7,43	5,40	8,35	261,60	3.466	208,80
SAT 0707	7,43	6,29	9,24	300,20	3.977	238,60
SAT 0708	7,43	7,18	10,13	338,80	4.488	269,30
SAT 0709	7,43	8,07	11,02	377,30	5.000	300,00
SAT 0710	7,43	8,96	11,91	415,90	5.511	330,70
SAT 0711	7,43	9,85	12,80	454,50	6.022	361,30
SAT 0712	7,43	10,74	13,69	493,10	6.534	392,00
SAT 0804	8,35	3,62	6,83	237,20	3.142	188,50
SAT 0805	8,35	4,51	7,72	285,90	3.788	227,30
SAT 0806	8,35	5,40	8,61	334,60	4.434	266,00
SAT 0807	8,35	6,29	9,50	383,40	5.080	304,80
SAT 0808	8,35	7,18	10,39	432,10	5.725	343,50
SAT 0809	8,35	8,07	11,28	480,08	6.371	382,30
SAT 0810	8,35	8,96	12,17	529,60	7.017	421,00
SAT 0811	8,35	9,85	13,06	578,30	7.663	459,80
SAT 0812	8,35	10,74	13,95	627,10	8.309	498,50
SAT 0813	8,35	11,63	14,84	675,80	8.954	537,30
SAT 0814	8,35	12,52	15,73	724,50	9.600	576,00
SAT 1106	11,14	5,40	9,42	618,70	8.198	491,90
SAT 1107	11,14	6,29	10,31	705,50	9.347	560,80
SAT 1108	11,14	7,18	11,20	792,20	10.497	629,80
SAT 1109	11,14	8,07	12,09	878,90	11.646	698,80
SAT 1110	11,14	8,96	12,98	965,70	12.795	767,70
SAT 1111	11,14	9,85	13,87	1.052,40	13.945	836,70
SAT 1112	11,14	10,74	14,76	1.139,20	15.094	905,70
SAT 1113	11,14	11,63	15,65	1.225,90	16.244	974,60
SAT 1114	11,14	12,52	16,54	1.312,70	17.393	1.043,60
SAT 1115	11,14	13,41	17,43	1.399,40	18.542	1.112,50
SAT 1116	11,14	14,30	18,32	1.486,20	19.692	1.181,50
SAT 1117	11,14	15,19	19,21	1.572,90	20.841	1.250,50
SAT 1118	11,14	16,08	20,10	1.659,70	21.991	1.319,40
SAT 1306	13,00	5,40	9,96	863,50	11.442	686,50
SAT 1307	13,00	6,29	10,85	981,70	13.007	780,40
SAT 1308	13,00	7,18	11,74	1.099,80	14.572	874,30
SAT 1309	13,00	8,07	12,63	1.217,90	16.137	968,20
SAT 1310	13,00	8,96	13,52	1.336,00	17.703	1.062,20
SAT 1311	13,00	9,85	14,41	1.454,20	19.268	1.156,10
SAT 1312	13,00	10,74	15,30	1.572,30	20.833	1.250,00
SAT 1313	13,00	11,63	16,19	1.690,40	22.398	1.343,90
SAT 1314	13,00	12,52	17,08	1.808,60	23.964	1.437,80
SAT 1315	13,00	13,41	17,97	1.926,70	25.529	1.531,70
SAT 1316	13,00	14,30	18,86	2.044,80	27.094	1.625,60
SAT 1317	13,00	15,19	19,75	2.163,00	28.659	1.719,60
SAT 1318	13,00	16,08	20,64	2.281,10	30.225	1.813,50
SAT 1406	14,85	5,40	10,59	1.154,00	15.290	917,40
SAT 1407	14,85	6,29	11,48	1.308,10	17.333	1.040,00
SAT 1408	14,85	7,18	12,37	1.462,30	19.375	1.162,50
SAT 1409	14,85	8,07	13,26	1.616,40	21.417	2.285,00
SAT 1410	14,85	8,96	14,15	1.770,60	23.460	1.407,60
SAT 1411	14.85	9,85	15,04	1.924,70	25.502	1.530,10
SAT 1412	14,85	10,74	15,93	2.078,90	27.545	1.652,70
SAT 1413	14,85	11,63	16,82	2.233,00	29.587	1.775,20
SAT 1414	14,85	12,52	17,71	2.387,10	31.630	1.897,80
SAT 1415	14,85	13,41	18,60	2.541,30	33.672	2.020,30
SAT 1416	14,85	14,30	19,49	2.695,40	35.715	2.142,90
SAT 1417	14,85	15,19	20,38	2.849,60	37.757	2.265,40
SAT 1418	14,85	16,08	21,27	3.003,70	39.799	2.388,00
SAT 1419	14,85	16,97	22,16	3.157,90	41.842	2.510,50
SAT 1420	14,85	17,86	23,05	3.312,00	43.884	2.633,10
SAT 1421	14,85	18,75	23,94	3.466,2	45.927	7.755,60
SAT 1422	14,85	19,64	24,83	3.620,30	47.969	2.878,20
SAT 1506	15,78	5,40	10,86	1.318,50	17.470	1.048,20
SAT 1507	15,78	6,29	11,75	1.492,50	19.776	1.186,60
SAT 1508	15,78	7,18	12,64	1.666,60	22.082	1.324,90
SAT 1509	15,78	8,07	13,53	1.840,70	24.389	1.463,30
SAT 1510	15,78	8,96	14,42	2.014,70	26.695	1.601,70
SAT 1511	15,78	9,85	15,31	2.188,80	29.001	1.740,10
SAT 1512	15,78	10,74	16,20	2.362,80	31.307	1.878,40
SAT 1513	15,78	11,63	17,09	2.536,90	33.614	2.016,80
SAT 1514	15,78	12,52	17,98	2.710,90	35.920	2.155,20
SAT 1515	15,78	13,41	18,87	2.885,00	38.226	2.293,60
SAT 1516	15,78	14,30	19,76	3.059,10	40.553	2.432,00
SAT 1517	15,78	15,19	20,65	3.233,10	42.839	2.570,30
SAT 1518	15,78	16,08	21,54	3.407,20	45.145	2.708,70
SAT 1519	15,78	16,97	22,43	3.581,20	47.451	2.847,10
SAT 1520	15,78	17,86	23,32	3.755,30	49.758	2.985,50
SAT 1521	15,78	18,75	24,21	3.929,40	54.064	3.123,80
SAT 1522	15,78	19,64	25,10	4.103,40	54.370	3.262,20
SAT 1808	18,56	7,18	13,44	2.369,40	31.394	1.883,70
SAT 1809	18,56	8,07	14,33	2.610,20	34.585	2.075,10
SAT 1810	18,56	8,96	15,22	2.851,00	37.775	2.266,50
SAT 1811	18,56	9,85	16,11	3.091,70	40.966	2.457,90
SAT 1812	18,56	10,74	17,00	3.332,50	44.156	2.649,40
SAT 1813	18,56	11,63	17,89	3.573,00	47.346	2.840,80
SAT 1814	18,56	12,52	18,78	3.814,10	50.537	3.032,20
SAT 1815	18,56	13,41	19,67	4.054,90	53.727	3.223,60
SAT 1816	18,56	14,30	20,56	4.295,70	56.918	3.415,10
SAT 1817	18,56	15,19	21,45	4.536,50	60.108	3.606,50
SAT 1818	18,56	16,08	22,34	4.777,30	63.299	3.797,90
SAT 1819	18,56	16,97	23,23	5.018,10	66.489	3.989,40
SAT 1820	18,56	17,86	24,12	5.258,80	69.680	4.180,80
SAT 1821	18,56	18,75	25,01	5.499,60	72.870	4.372,20
SAT 1821	18,56	18,75	25,01	5.499,6	72.870	4.372,2
SAT 1822	18,56	19,64	25,90	5.740,40	76.061	4.563,60
SAT 2208	22,28	7,18	14,51	3.537,40	46.871	2.812,30
SAT 2209	22,28	8,07	15,40	3.884,40	51.469	3.088,10
SAT 2210	22,28	8,96	16,29	4.231,40	56.066	3.364,00
SAT 2211	22,28	9,85	17,18	4.578,40	60.664	3.639,80
SAT 2212	22,28	10,74	18,07	4.925,4	65.261	3.915,70
SAT 2213	22,28	11,63	18,96	5.272,40	69.859	4.191,50
SAT 2214	22,28	12,52	19,85	5.619,40	74.457	4.467,40
SAT 2215	22,28	13,41	20,74	5.966,30	79.054	4.743,20
SAT 2216	22,28	14,30	21,63	6.313,30	83.652	5.019,10
SAT 2217	22,28	15,19	22,52	6.660,30	88.249	5.295,00
SAT 2218	22,28	16,08	23,41	7.007,30	92.847	5.570,80
SAT 2219	22,28	16,97	24,30	7.354,30	97.444	5.846,70
SAT 2220	22,28	17,86	25,19	7.701,30	102.042	6.122,50
SAT 2221	22,28	18,75	26,08	8.048,30	106.639	6.398,40
SAT 2222	22,28	19,64	26,97	8.395,20	111.237	6.674,20
SAT 2708	27,85	7,18	16,12	5.811,60	76.837	4.610,20
SAT 2709	27,85	8,07	17,01	6.353,50	84.001	5.040,10
SAT 2710	27,85	8,96	17,90	6.895,4	91.166	5.470,0
SAT 2711	27,85	9,85	18,79	7.437,30	98.330	5.899,80
SAT 2712	27,85	10,74	19,68	7.979,20	105.495	6.329,70
SAT 2713	27,85	11,63	20,57	8.521,10	112.659	6.759,60
SAT 2714	27,85	12,52	21,46	9.063,00	119.824	7.189,40
SAT 2715	27,85	13,41	22,35	9.604,9	126.988	7.619,30
SAT 2716	27,85	14,30	23,24	10.146,70	134.153	8.049,20
SAT 2717	27,85	15,19	24,13	10.688,60	141.317	8.479,00
SAT 2718	27,85	16,08	25,02	11.230,50	148.482	8.908,90
SAT 2719	27,85	16,97	25,91	11.772,40	155.646	9.338,80
SAT 2720	27,85	17,86	26,80	12.314,30	162.810	9.768,60
SAT 2721	27,85	18,75	27,69	12.856,20	169.975	10.198,50
SAT 2722	27,85	19,64	28,58	13.398,10	177.139	10.628,40
SAT 3208	32,49	7,18	17,46	8.236,00	108.890	6.533,40
SAT 3209	32,49	8,07	18,35	8.973,50	118.641	7.118,40
SAT 3210	32,49	8,96	19,24	9.711,00	128.391	7.703,50
SAT 3211	32,49	9,85	20,13	10.448,50	138.142	8.288,50
SAT 3212	32,49	10,74	21,02	11.186,00	147.892	8.873,50
SAT 3213	32,49	11,63	21,91	11.923,50	157.643	9.458,60
SAT 3214	32,49	12,52	22,8	12.661,00	167.394	10.043,60
SAT 3215	32,49	13,41	23,69	13.398,40	177.144	10.628,70
SAT 3216	32,49	14,3	24,58	14.135,90	186.895	11.213,70
SAT 3217	32,49	15,19	25,47	14.873,40	196.645	11.798,70
SAT 3218	32,49	16,08	26,36	15.610,90	206.396	12.383,80
SAT 3219	32,49	16,97	27,25	16.348,40	216.147	12.968,80
SAT 3220	32,49	17,86	28,14	17.085,90	225.897	13.553,80
SAT 3221	32,49	18,75	29,03	17.823,40	235.648	14.138,90
SAT 3222	32,49	19,64	29,92	18.560,90	245.398	14.723,90
